| Sl.No | Description | Size |
|---|---|---|
| 1 | DTH drilling: Drilling diameter Depth (Vertical) Depth(Horizontal) | 3.5"-4.5"(90-115mm) 30meters 20meters |
| 2 | Rotary Head BHP RPM Max.Torque | 4 cylinder piston type air motor with spur type reduction gearbox. 4.5 0-50 1125Nm |
| 3 | Feed System Pull up/Pull down Pull up and pull down speed Type of feed BHP | 4 cylinder type air motor with spur cum worm drive gearbox 0-2000kgf/0-2000kgf 0-15mtr/minute Chain feed 4.5 |
| 4 | Air line Lubricator | Provided |
| 5 | General dimensions & weight Height/Depth/Width of rig Weight | 3000mm/600mm/600mm 470kg |
| 6 | Air compressor Free Air Delivery Working pressure | Min Max 10.3 m3/min(365 cfm) 12.7 m3/min(450cfm) 7.03kg/cm2(100psi) 10.5kg/cm2(150psi) |
